RSDW08F-05
8W I/P: 9-36VDC; O/P: 5V@1600mA, 5Vdc DC/DC Converter Ultra Wide 4:1 Input Range DIP-24, Railway, 8 WattsManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$19.97
10
$19.71
25
$19.46
50
$19.21
100
$18.73
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9~36Vdc
Output Voltage:
5Vdc
Output Max Current:
1.6 Amps
Max Power:
8 Watts
Known Country of Origin:
China
Features
Ultra wide 4:1 input voltage range
Operating temperature range: -40~+85°C
Complies to EN 50155 railway standard
1500Vdc I/O isolation
Single output
No minimum load required
Remote On/Off
Protections: continuous short circuit / over load / over voltage / input under voltage
MEAN WELL 3 year warranty
