Power Worth Searching For
RSDW40G-05
40W I/P: 18-75VDC; O/P: 5V@8A, DC/DC Converter 2x1 2:1 Input, 40 WattsManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$43.85
10
$43.27
25
$42.71
50
$42.17
100
$41.11
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
5Vdc
Output Max Current:
8 Amps
Max Power:
40 Watts
Known Country of Origin:
Taiwan
Features
Ultra-Wide 4:1 input range
Operating temperature range: -40~+90°C
Compliance to EN 50155 railway standard
Compliance to IEC 61373 for shock & vibration
I/O isolation: 1600Vdc (F/G models), 3000Vdc (H models)
No minimum load required
Fully regulated output
Remote On/Off
Protections: short circuit / overload / overvoltage / over temperature / input under voltage
MEAN WELL 3 year warranty
