TEN 40-11013WIRH
15Vdc 2.66A, DC/DC Converter 2x1 Package, Railway 4:1 InputManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
36~160Vdc
Output Voltage:
15Vdc
Output Max Current:
2.66 Amps
Max Power:
40 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TEN 40-11013WIRH high performance DIP package DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature range: -40~+70°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Compliance to EN 50155 railway standard
Compliance to IEC 61373 for shock & vibration
I/O isolation: 3000Vac
MIL-STD-810F
No minimum load required
Remote On/Off
Operation up to 5000m altitude
Under voltage lock-out circuit
Protections: short circuit / over temperature / overvoltage (single output models only)
TRACO Power 3 year warranty
