DPUN02N-05
2 W; I/P:24V+/-10%; O/P:+/- 5V@+/-200mA; 3KV DC/DC Converter Unregulated, SIP13Manufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$5.35
10
$5.28
25
$5.22
50
$5.15
100
$5.02
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
21.6~26.4Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
0.2 Amps
Output Voltage #2:
-5Vdc
Output #2 Max Current:
0.2 Amps
Max Power:
2 Watts
Known Country of Origin:
China
Features
Operating temperature range: -40~+105°C
Complies to EN55032 radiated Class A without additional components
I/O isolation up to 3,000Vdc
Protections: short circuit / over load
MEAN WELL 3 year warranty
