TMR 8-1222WI
Dual O/P, DC-DC Converter SIP-8 Package Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$25.23
10
$23.34
25
$23.03
100
$20.22
Click for Quote for higher qty discounts
Specifications
Input Voltage:
4.5~18Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
.335 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
.335 Amps
Max Power:
8 Watts
Known Country of Origin:
Taiwan
Features
Ultra compact SIP8 plastic case
Wide input range: 4.5~18Vdc
Operating temperature range: -40~+90°C
Safety Approvals: IEC/EN/UL 62368-1
I/O isolation: 1500Vdc
Operating up to 6000m altitude
No minimum load required
Under voltage lockout
Fully regulated outputs
Remote On/Off control
Protections: short circuit / over load
TRACO Power 3 year warranty
