TES 2-1211M
5Vdc 0.4A, Medical DC-DC Converter SMD Package 2XMOOPManufacturer: TRACO Power
View Data Sheet
In Stock: 2 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$31.00
10
$25.82
25
$25.48
100
$20.37
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
10.8~13.2Vdc
Output Voltage:
5Vdc
Output Max Current:
0.4 Amps
Max Power:
2 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TES 2-1211M ultra compact SMD medical DC/DC converter
Operating temperature: -25~+80°C
Medical safety approvals: AAMI/ANSI ES 60601-1:2005(R)& IEC/EN 60601-1 3rd edition
2xMOOP
Industrial safety approvals: UL/IEC/EN 60950-1
I/O isolation 4000Vacrms rated for 300 Vrms working voltage
Available tape and reel package
Short circuit protection
TRACO Power 3 year warranty
