Power Worth Searching For
TES 5-4811WI
5Vdc 1A, DC-DC Converter SMD Package Wide 4:1 Input Voltage RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$50.43
10
$39.09
25
$38.56
100
$31.30
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
5Vdc
Output Max Current:
1 Amps
Max Power:
5 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TES 5-4811WI compact SMD package DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+71°C
Compact footprint: 33.4x25.6mm
I/O isolation 1500Vdc
Input filter to meet EN 55022, class A
High accuracy of pin co-planarity
Remote On/Off
Short circuit protection
TRACO Power 3 year warranty
