ISM0124D12
Dual O/P, Medical DC/DC Converter, SMD PackageManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$24.71
5
$23.96
10
$23.22
25
$22.24
100
$20.76
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
21.6~26.4Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.042 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.042 Amps
Max Power:
1 Watts
Known Country of Origin:
Taiwan
Features
XP Power ISM0124D12 Medical DC/DC converter
Operating temperature range: -40~+105°C
Medical safety certification: IEC 60601-1, ANSI/AAMI ES 60601-1
2xMOPP
I/O isolation: 4000Vac
Low leakage current ≤2µA
Unregulated output
Protections: short circuit
XP Power 3 year warranty
