Dual O/P, Dual Output DC/DC Converter Ultra Wide 4:1 Input Range Ultra Compact DIP-16 PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.416 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.416 Amps
Max Power:
10 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TEL 10-4822WI ultra compact DIP-16 package DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+88°C
Safety approvals: IEC/EN/UL 62368-1 & IEC/EN/UL 60950-1
Built-in EN 55032 Class A filter
6-side shielded metal case with insulated baseplate
No minimum load required
I/O isolation 1500Vdc
Protections: short circuit / overload
TRACO Power 3 year warranty
