Power Worth Searching For
TEL 8-1212
12Vdc 0.665A, DC-DC Converter DIP-16 PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
9~18Vdc
Output Voltage:
12Vdc
Output Max Current:
0.665 Amps
Max Power:
8 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TEL 8-1212 highly efficient DIP-16 package DC/DC Converter
Wide 2:1 input voltage ranges
Operating temperature: -40~+80°C
Regulated output
Built-in EN55022 class A filter
Compact metal casing
Short circuit protection
TRACO Power 3 year warranty
TEL 8-1212
12Vdc 0.665A, DC-DC Converter DIP-16 PackageManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
9~18Vdc
Output Voltage:
12Vdc
Output Max Current:
0.665 Amps
Max Power:
8 Watts
Known Country of Origin:
Taiwan
Features
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
