TEN 3-0510
3.3Vdc 0.6A, DC-DC Converter DIP-24 PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$23.05
10
$19.20
25
$18.94
100
$15.37
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
4.5~9Vdc
Output Voltage:
3.3Vdc
Output Max Current:
0.6 Amps
Max Power:
3 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TEN 3-0510 highly efficient DIP-24 package DC/DC converter
Wide 2:1 input voltage ranges
Operating temperature: -40~+85°C
Input filter meets EN55022, class A and FCC level A without external components
I/O isolation 1500Vdc
Short circuit protection
TRACO Power 3 year warranty
TEN 3-0510
3.3Vdc 0.6A, DC-DC Converter DIP-24 PackageManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
4.5~9Vdc
Output Voltage:
3.3Vdc
Output Max Current:
0.6 Amps
Max Power:
3 Watts
Known Country of Origin:
Taiwan
Features
