TEN 40-4810E
3.3Vdc 12.2A, 2x1 DC/DC Converter 2:1 Wide Input RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
36~75Vdc
Output Voltage:
3.3Vdc
Output Max Current:
12.2 Amps
Max Power:
40 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TEN 40-4810E 2x1 inches metal package (6-side shielded) DC/DC converter
Wide 2:1 input voltage range
Operating temperature range: -40~+85°C
Industrial safety certifications: UL/IEC/EN 62368-1
I/O isolation 1600Vdc
High efficiency
Remote On/Off and trim function
Protections: over voltage / over temperature / short circuit
TRACO Power 3 year warranty
