Power Worth Searching For
TEN 40-4822WI
Dual O/P, DC-DC Converter 2x2Manufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$130.10
10
$106.52
25
$103.76
50
$90.53
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
1.65 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
1.65 Amps
Max Power:
40 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TEN 40-4822WI 2x2 inch low profile DC/DC converter
Ultra wide 4:1 input range
Operating temperature: -40~+85°C
Safety approvals: UL/IEC/EN 60950-1
No minimum load required for single output models
Shielded metal package with insulated baseplate
Under voltage lockout
Remote On/Off
Protections: short circuit / over load / over voltage / thermal shutdown /over temperature
Optional heat sink available
TRACO Power 3 year warranty
TEN 40-4822WI
Dual O/P, DC-DC Converter 2x2Manufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
1.65 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
1.65 Amps
Max Power:
40 Watts
Known Country of Origin:
Taiwan
Features
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$130.10
10
$106.52
25
$103.76
50
$90.53
REQUEST a QUOTE for higher qty discounts
