THD 10-2410N
3.3Vdc 2.7A, DC-DC Converter DIP-24 Package 2:1 Input RangeManufacturer: TRACO Power
View Data Sheet
In Stock: 5 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~36Vdc
Output Voltage:
3.3Vdc
Output Max Current:
2.7 Amps
Max Power:
10 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power THD 10-2410N DIP-24 package DC/DC converter
Wide 2:1 input voltage range
Operating temperature: -40~+85°C
Internal EMI-filter meets EN55022, class A without external components
I/O isolation 1500Vdc
High efficiency
No minimum load required
Protections: over load / short circuit
TRACO Power 3 year warranty
