THL 15-2412WI
12Vdc 1.25A, DC/DC Converter Ultra Wide 4:1 Input Range 15W, 1x1 Inch DIP PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
9~36Vdc
Output Voltage:
12Vdc
Output Max Current:
1.25 Amps
Max Power:
15 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power THL 15-2412WI high power density 1x1 inch DC/DC converter
Ultra wide 4:1 input voltage ranges
Operating temperature: -40~+90°C
Safety approvals: IEC 62368-1
I/O isolation 1500Vdc
Shielded metal case with isolated baseplate
Input filter to meet EN 55022, class A
Optional heat-sink available
Remote On/Off
Protections: short circuit / over voltage / over load
TRACO Power 3 year warranty
