THM 60-2411WI
5.1Vdc 12A, Medical DC-DC Converter DIP Package 2xMOPP, 4:1 InputManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$188.96
10
$174.56
25
$169.78
50
$163.65
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9~36Vdc
Output Voltage:
5.1Vdc
Output Max Current:
12 Amps
Max Power:
60 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power THM 60-2411WI DIP package medical DC/DC converter
Ultra-Wide 4:1 input range
Operating temperature range: -40~+75°C
Medical safety certification: ANSI/AAMI ES/IEC/EN 60601-1
EMC emission compliant to IEC 60601-1-2 4th edition
2xMOPP
Low leakage current ≤4.5µA
Industrial safety certification: IEC/EN 62368-1, UL 62381-1
I/O isolation: 5000Vac
MIL-STD-810F
Meets EN 55032 class A with external filter
EMC emission compliant to EN55032 Class B with external filter
Fully regulated output
No minimum load required
Remote On/Off
Operation up to 5000m altitude
Under voltage lock-out circuit
Protections: short circuit / over temperature / overvoltage
TRACO Power 5 year warranty
