THI 2-0523M
Dual O/P, Medical DC-DC Converter DIP-16 Package 2XMOOPManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$33.23
10
$27.64
25
$27.27
100
$21.80
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
4.5~5.5Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.066 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
0.066 Amps
Max Power:
2 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power THI 2-0523M ultra compact DIP-16 medical DC/DC converter
Operating temperature: -40~+71°C
Medical safety approvals: UL 60601-1 & IEC/EN 60601-1 3rd edition
2xMOOP
Industrial safety approvals: UL/IEC/EN 60950-1
I/O isolation 3000Vacrms rated for 300 Vrms working voltage
Short circuit protection
TRACO Power 3 year warranty
