TIM 3.5-4823SM
Dual O/P, Medical DC/DC Converter Wide 2:1 Input Range SMD Package, Dual OutputManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$46.57
10
$44.35
25
$43.76
100
$37.23
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
36~72Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.117 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-0.117 Amps
Max Power:
3 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TIM 3.5-4823SM compact SMD-16 package DC/DC Converter
Wide 2:1 input voltage range
Operating temperature: -40~+95°C
Safety approvals: ANSI/AAMI ES 60601-1 & IEC/EN 60601-1 3rd edition
2xMOPP
I/O isolation 5000VACrms rated for 250 VACrms working voltage
Low leakage current <2µA for BF applications
Protections: short circuit / over voltage
TRACO Power 5 year warranty
