TMM 24115
15Vdc 1.6A, 15 Volt Power Supply Medical & ITE Safety PCB MountManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~264Vac
Output Voltage:
15Vdc
Output Max Current:
1.6 Amps
Max Power:
24 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TMM 24115 fully encapsulated PCB mount medical power supply
Universal AC input range: 85~264Vac
Operating temperature: -40~+80°C
Medical safety approvals: AAMI/ANSI ES 60601-1:2005(R) & IEC/EN 60601-1 3rd edition
2xMOPP
ITE safety approval: IEC/EN/UL 60950-1
Class II
No load power consumption <0.3W
Protections: short circuit / over load / over temperature
TRACO Power 3 year warranty
