TEN 40-7215UIR
24Vdc 1.67A, 40 Watt, 24V, 1.67A, 14~160 Volt (12:1) Ultra-wide Input Range, 2x1 Railway DC/DC ConverterManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$121.68
10
$102.45
25
$99.79
50
$87.69
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
14~160Vdc
Output Voltage:
24Vdc
Output Max Current:
1.67 Amps
Max Power:
40 Watts
Known Country of Origin:
Taiwan
Features
2x1, fully encapsulated, railway DC/DC converter w-built-in heat sink
Ultra wide 12:1 input range
Operating temperature range: -40~+90°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Certified to EN 50155 railway standard
Certified to EN 61373 for shock & vibration
MIL-STD-810F
I/O isolation: 3000Vdc
Built-in remote On/Off
Adjustable output voltage
Operation up to 5000m altitude
Under voltage lock-out circuit
Over voltage category II
Protections: short circuit / overvoltage / over temperature
TRACO Power 3 year warranty
