THN 20-4812WIR
12Vdc 1.67A, DC/DC Converter 1x1 Package, EN 50155 Railway 4:1 InputManufacturer: TRACO Power
View Data Sheet
In Stock: 10 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
12Vdc
Output Max Current:
1.67 Amps
Max Power:
20 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power THN 20-4812WIR 1x1 inches railway DC/DC converter
Ultra-wide 4:1 input range
Operating temperature range: -40~+85°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
MIL-STD-810F
Compliance to EN 61373 for shock and vibration
Compliance to EN 50155 railway standard
I/O isolation: 3000Vdc
Adjustable output voltage
Output voltage trim function (single output models)
Remote On/Off
Fully regulated output
Protections: short circuit / overload / overvoltage / undervoltage-lockout
TRACO Power 3 year warranty
