TMR 6-7221WIR
Dual O/P, Dual Output DC/DC Converter Wide Input Voltage Range Compact SIP-8 Package, RailwayManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$42.71
10
$36.04
25
$35.56
100
$31.30
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
43~160Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
0.6 Amps
Output Voltage #2:
-5Vdc
Output #2 Max Current:
-0.6 Amps
Max Power:
6 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TMR 6-7221WIR compact SIP-8 package railway DC/DC converter
Ultra wide input voltage range
Operating temperature: -40~+80°C
Safety approvals: IEC/EN/UL 60950-1
EN 50155 railway approval
Metal case
Remote On/Off
I/O isolation 3000Vdc
Fully regulated outputs
Protections: short circuit / overload
TRACO Power 3 year warranty
TMR 6-7221WIR
Dual O/P, Dual Output DC/DC Converter Wide Input Voltage Range Compact SIP-8 Package, RailwayManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
43~160Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
0.6 Amps
Output Voltage #2:
-5Vdc
Output #2 Max Current:
-0.6 Amps
Max Power:
6 Watts
Known Country of Origin:
Taiwan
Features
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$42.71
10
$36.04
25
$35.56
100
$31.30
REQUEST a QUOTE for higher qty discounts
