DSR75PS48
48Vdc 1.6A, 48V DIN Rail DPower Supply, Peak Current, 48 Volts 1.6 AmpsManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~264Vac
Output Voltage:
48Vdc
Output Max Current:
1.6 Amps
Output Peak Current:
2.4 Amps
Max Power:
75 Watts
Known Country of Origin:
Not specified
Features
XP Power DSR75PS48 low profile DIN rail power supply
AC input range: 85~264Vac
Operating temperature range: -25~+70°C
Industrial safety certification: EN 62368-1, UL 60950-1
UL 508 listed
No minimum load required
Peak power 150% for 3 seconds
Built-in PFC
Low leakage current ≤1.0mA
Parallel function
High efficiency
Adjustable output voltage
LED indicator for DC OK
DC OK signal
Operating up to 5000m altitude
Protections: overvoltage / overload / short circuit
XP Power 3 year warranty
