HRL3024S350N
-350Vdc 0.0857A, Single O/P DC-HV DC PCB Mount 30W, -350VManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
22~30Vdc
Output Voltage:
-350Vdc
Output Max Current:
85.7 mAmps
Max Power:
30 Watts
Known Country of Origin:
Vietnam
Features
Programmable high voltage DC/DC converter
22~30Vdc input range
Operating temperature range: -40~+70°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1, UL 60950-1
0 to 100% programmable output voltage & current
Voltage & current monitor outputs
Built-in Remote On/Off
No minimum load required
Fully regulated output
Protections: short circuit / overload / undervoltage-lockout / over temperature / input overvoltage / over programming
XP Power 3 year warranty
