QHL150300S48
48Vdc 3.2A, DC/DC Converter, Quarter BrickManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$193.46
5
$187.66
10
$181.86
25
$174.12
100
$162.50
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
180~425Vdc
Output Voltage:
48Vdc
Output Max Current:
3.2 Amps
Max Power:
150 Watts
Known Country of Origin:
Taiwan
Features
XP Power QHL150300S48 industrial DC/DC converter
180~425Vdc input range
Operating temperature range: -40~+100°C
Industrial safety certification: UL 60950-1
MIL-STD-810F
Compliance to IEC 61373 for shock and vibration
I/O isolation: 3000Vac
No minimum load required
Remote On/Off
Remote sense function
Output voltage trim function
Fully regulated output
Protections: short circuit / overload / overvoltage / over temperature / undervoltage-lockout
XP Power 3 year warranty
