JCK2024S15
15Vdc 1.33A, DC/DC ConverterManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$51.48
5
$49.93
10
$48.40
25
$46.33
100
$43.25
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
18~36Vdc
Output Voltage:
15Vdc
Output Max Current:
1.33 Amps
Max Power:
20 Watts
Known Country of Origin:
Taiwan
Features
XP Power JCK2024S15 2x1 inches DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+100°C
I/O isolation: 1600Vac
No minimum load required
Output voltage trim function
Remote On/Off
Fully regulated output
Protections: short circuit / overload / overvoltage / undervoltage lockout
XP Power 3 year warranty
