JTH1524D12
Dual O/P, DC/DC ConverterManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$56.54
5
$54.85
10
$53.15
25
$50.89
100
$47.50
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9~36Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.625 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.625 Amps
Max Power:
15 Watts
Known Country of Origin:
Taiwan
Features
XP Power JTH1524D12 2x1 inches DC/DC converter
Ultra-wide 4:1 input range
Operating temperature range: -40~+100°C
Industrial safety certification: UL 60950-1, UL 62368-1
I/O isolation: 1500Vdc
No minimum load required
Remote On/Off (-R models only)
Fully regulated output
Protections: short circuit / overcurrent / overvoltage / undervoltage-lockout
XP Power 3 year warranty
