AA150M-240B-R
24V Desk Top Power Adaptor, Low Profile, IEC320 C6 InputManufacturer: Phihong
View Data Sheet
Specifications
Input Voltage:
90~264Vac
Output Voltage:
24Vdc
Output Max Current:
6.25 Amps
Max Power:
150 Watts
Known Country of Origin:
Not specified
Features
Industrial desktop adaptor
AC input range: 90~264Vac
Operating temperature range: -5~+40°C (19V/24V) / -20~+40°C (48V/54V)
Industrial safety certification: IEC 62368-1, UL 62368-1
Energy Efficiency Level VI
Operation up to 5000m altitude
Low leakage current ≤250µA
AC inlet: IEC320 C6
DC plug type: 2.5 x 5.5 x 11.0mm center positive
Protections: short circuit / overvoltage / overcurrent
Phihong 1 year warranty
