THI 1220
Dual O/P, DC-DC Converter DIP-24 PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
Factory Stock: 90 i If factory stock is available, we can typically ship that additional stock from the factory to you within two weeks. Contact us to confirm timing for your quantity.
Quantity
Unit Price
1
$42.30
10
$35.19
25
$34.72
100
$27.75
Click for Quote for higher qty discounts
Specifications
Input Voltage:
10.8~13.2Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
0.1 Amps
Output Voltage #2:
-5Vdc
Output #2 Max Current:
0.1 Amps
Max Power:
2 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power THI 1220 DIP-24 package DC/DC converter
Operating temperature: -40~+85°C
I/O isolation voltage 2500Vacrms
Supplementary insulation rated for working voltage up to 250Vac
Regulated output
Low coupling capacity
Short circuit protection
TRACO Power 3 year warranty
