TRI 6-4822
Dual O/P, 6 Watt DC/DC Converter High Isolation, Regulated Compact DIP-24 PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
Factory Stock: 90 i If factory stock is available, we can typically ship that additional stock from the factory to you within two weeks. Contact us to confirm timing for your quantity.
Specifications
Input Voltage:
36~75Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.115 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
0.115 Amps
Max Power:
3 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TRI 6-4822 DIP-24 package DC/DC converter
Wide 2:1 input voltage range
Operating temperature range: -40~+95°C
Industrial safety approval: UL/EN/IEC 62368-1
Reinforced I/O isolation up to 7071Vdc (9000Vdc peak for 1 sec)
Low no-load power consumption 120-240mW
Protections: short circuit / over load / over voltage
TRACO Power 3 year warranty
