TRN 3-4821
Dual O/P, DC/DC Converter Wide 2:1 Input Voltage Range SIP PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$26.68
10
$23.86
25
$23.54
100
$19.29
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
36~75Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.1 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-0.1 Amps
Max Power:
3 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TRN 3-4821 compact SIP package DC/DC converter
Wide 2:1 input voltage range
Operating temperature range: -40~+85°C
Safety approvals: UL 60950-1 & IEC/EN 60950-1
I/O isolation 1,600Vdc
Fully regulated outputs
Protection: short circuit
TRACO Power 3 year warranty
