TSM 1212D
Dual O/P, DC-DC Converter SMD Package I/O Isolation 1000 VoltManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
10.8~13.2Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.04 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
0.04 Amps
Max Power:
1 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TSM 1212D compact SMD package DC/DC converter
Operating temperature: -40~+85°C
I/O isolation 1,000Vdc
High accuracy of pin co-planarity
High efficiency
Available in tape and reel package
Protection: short circuit
TRACO Power 3 years warranty
