ECL15UD01-S
12V,-12V, Dual Output Power Supply, Screw Terminal I/OManufacturer: XP Power
View Data Sheet
Specifications
Input Voltage:
85~264Vac
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.65 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
0.65 Amps
Max Power:
15 Watts
Known Country of Origin:
China
Features
XP Power ECL15UD01-S encapsulated chassis mount screw terminal power supply
AC input range: 85~264Vac
Operating temperature range: -20~+70°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Dual output models
Class II
Peak power up to 130% for <30 sec
Reinforced I/O isolation 3000Vac
No load power consumption <0.3W
Protections: overvoltage / overload / short circuit
XP Power 3 year warranty
