Specifications
Input Voltage:
36~72Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.416 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.416 Amps
Max Power:
10 Watts
Known Country of Origin:
Taiwan
Features
XP Power JCH1048D12 2x1 inches DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+100°C
Industrial safety certification: UL 60950-1, UL 62368-1
I/O isolation: 1500Vdc
No minimum load required
Fully regulated output
Protections: short circuit / overload
XP Power 3 year warranty
JCH1048D12
Dual O/P, DC/DC ConverterManufacturer: XP Power
View Data Sheet
Specifications
Input Voltage:
36~72Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.416 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.416 Amps
Max Power:
10 Watts
Known Country of Origin:
Taiwan
Features
XP Power JCH1048D12 2x1 inches DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+100°C
Industrial safety certification: UL 60950-1, UL 62368-1
I/O isolation: 1500Vdc
No minimum load required
Fully regulated output
Protections: short circuit / overload
XP Power 3 year warranty
