Power Worth Searching For
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
3.3Vdc
Output Max Current:
7.5 Amps
Max Power:
30 Watts
Known Country of Origin:
Taiwan
Features
XP Power JTL3048S3V3 2x1 inches DC/DC converter
Ultra-wide 4:1 input range
Operating temperature range: -40~+75°C
I/O isolation: 1600Vdc
No minimum load required (single & dual output models)
Remote On/Off
Adjustable output voltage (single output models only)
Fully regulated output
Protections: short circuit / overload / overvoltage / over temperature / undervoltage-lockout
XP Power 3 year warranty
JTL3048S3V3
3.3Vdc 7.5A, DC/DC ConverterManufacturer: XP Power
View Data Sheet
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
3.3Vdc
Output Max Current:
7.5 Amps
Max Power:
30 Watts
Known Country of Origin:
Taiwan
Features
XP Power JTL3048S3V3 2x1 inches DC/DC converter
Ultra-wide 4:1 input range
Operating temperature range: -40~+75°C
I/O isolation: 1600Vdc
No minimum load required (single & dual output models)
Remote On/Off
Adjustable output voltage (single output models only)
Fully regulated output
Protections: short circuit / overload / overvoltage / over temperature / undervoltage-lockout
XP Power 3 year warranty
